Key Features

1500W of Power
123 dB Maximum SPL
10" Low-Frequency Woofer
8 x 2" High-Frequency Drivers
Five-Channel Mixer with Bluetooth Audio
3 Channels of Mic/Line Inputs
Summed 3.5mm / Bluetooth Input
1 Hi-Z 1/4" Input + 1/4" Passthrough
Easily Swappable Battery: 6-Hour Life
Includes Column Spacer & IEC Power Cord

Overview

Performing musicians, singer/songwriters, and audio professionals looking for a compact, all-in-one PA system will be impressed with the JBL EON ONE MK2, a self-contained PA system that delivers professional-quality audio for live performances, meetings, conferences, and more. The base unit houses a 1500W amplifier, 10" unobstructed subwoofer, and the 5-channel mixer. The high-frequency element features a C-shaped array of eight 2" tweeters to deliver superior clarity and 170°H x 30°V dispersion for room-filling sound, creating a remarkable front-to-back coverage.

Channels 1-3 on the mixer offer XLR-1/4" connectors, while input 4 features a 1/4" Hi-Z input for use with guitars or other instruments. A 3.5mm TRS summed input allows you to connect a portable playback device. The 5th input also doubles as the Bluetooth audio input for wireless audio streaming and control of up to 10 units. The mixer features three fixed EQ knobs for fast, hands-on access to the onboard EQ.

Additionally, the EON ONE MK2 features a comprehensive suite of professional-grade Lexicon DSP, including reverb, delay, and chorus. dbx DriveRack technology offers Automatic Feedback Suppression (AFS) and 8-band parametric EQ as well as convenient presets to help you get the best sound fast. Should you wish to connect additional speakers, a 1/4" passthrough with independent volume control and speaker delay allows for analog system expansion.

Key Specs

Speaker Configuration	1x 2-Way Speaker Column with Subwoofer
Number of Input Channels	5 (4 x Mono, 1 x Stereo)
Amplifier Power Rating	1500 W
HF Driver	8x 2" / 50.8 mm
LF Driver	1x 10" / 254 mm Woofer
Audio I/O	3x Combo XLR-1/4" TRS Female Balanced Mic/Line Input 1x 1/4" TS Female Unbalanced Hi-Z Input 1x 1/8" / 3.5 mm TRS Female Unbalanced Line Input 1x 1/4" TRS Female Balanced Line Thru/Output
USB I/O	2x USB-A (Device Charging)
Bluetooth	5.0

Portable PA System

Speaker Configuration	1x 2-Way Speaker Column with Subwoofer
Number of Input Channels	5 (4 x Mono, 1 x Stereo)
Amplifier Power Rating	1500 W

Speakers

Enclosure Type	Bass-Reflex
HF Driver	8x 2" / 50.8 mm
LF Driver	1x 10" / 254 mm Woofer

Signal Processing

Crossover	230 Hz
EQ	HF Shelf MF Notch/Peak LF Shelf
Semi-Parametric EQ	No
Effects	Reverb Delay Chorus
Filters	No
Dynamic Processing	Limiter

Performance

Frequency Range	37 Hz to 20 kHz -10 dB 45 Hz to 20 kHz ±3 dB
Maximum SPL	119 dB 123 dB
Coverage Angle	170° H x 30° V
I/O Impedance	XLR Mic Input: 4 Kilohms (Balanced) 1/4" TRS Low-Z Input: 4 Kilohms (Balanced) 1/4" Hi-Z Input: 2 Megohms (Unbalanced) 1/8" / 3.5 mm Line Input: 10 Kilohms (Unbalanced)

Connectivity

Audio I/O	3x Combo XLR-1/4" TRS Female Balanced Mic/Line Input 1x 1/4" TS Female Unbalanced Hi-Z Input 1x 1/8" / 3.5 mm TRS Female Unbalanced Line Input 1x 1/4" TRS Female Balanced Line Thru/Output
Phantom Power	+48 V (Switchable)
USB I/O	2x USB-A (Device Charging)
Wireless Connectivity	Bluetooth
Bluetooth	5.0

Power

Battery Type	1x Built-In Rechargeable 36 V Lithium-Ion (Replaceable)
Approximate Battery Life	6 Hours
AC Input Power	100 to 120 VAC, 50 / 60 Hz
Power Consumption	300 W
AC Power I/O	1x IEC Input

Physical

Transport Options	1x Handle (Top)
Construction Material	Perforated Metal Grille, Polypropylene
Dimensions	28.7 x 24.7 x 17.8" / 729 x 627.4 x 452.1 mm
Weight	42.5 lb / 19.3 kg

What's in the Box:

JBL EON ONE MK2 All-in-One, Battery-Powered Column PA with Built-In Mixer and DSP
EON ONE MK2 Base
Column Speaker Array
Column Spacer
Power Cable
Limited 2-Year Manufacturer Warranty
